Module 5: Case Studies



Module 5 Objectives

  1. Develop an appreciation of How Nodal Analysis can be applied to solve “real-life” problems
  2. Defining the problem, developing a project-specific work methodology
  3. Building Cases, running Sensitivities
  4. The bigger picture: Understanding the full implication of calculation results


Module 5 Contents

  1. Natural Flow (Optimising Tubing Size)
  2. Electric Submersible Pump (Pump Operating Envelope)
  3. Hydraulic Submersible Pump (Pump Operating Envelope)
  4. Gas Lift
  5. Performance Curve
  6. Tubing Punch
  7. Gas Lift Design
  8. Gas Well: Developing a full Life Cycle Completion & Well Remediation Strategy
  9. CT-ESP: Defining a Practical Operating Envelope (ESP deployed via Coiled Tubing)



Course Fee Includes

  • 5 days access to two, pre-recorded videos



Recommended Skills Level: Intermediate


MODULE 5 is aimed at engineers who know what the inflow/outflow curves are, and understand how they are impacted by changes in producing conditions such as WC, WHP, Pres, GOR, etc.

If you are new to Nodal Analysis, MODULE 1 is recommended before taking MODULE 5.

– Course Curriculum –

Module 5: Case Studies (Single-Well Models)

  Module 5: Case Studies
Available in days
days after you enroll

Course Fee – MODULE 5
